UNIXPADEL – Retractable Side and Roof Canopy System

3. Manufacturing & Welding

  • Manufacturing processes adhere to ISO 9001:2015 Quality Management System
  • Welding procedures meet ISO 3834 international standards
  • Certified facilities ensure precision and structural safety across all joints and profiles

4. Coating & Corrosion Protection

  • All steel elements undergo hot-dip galvanization according to TS EN ISO 1461 and ASTM A123 standards
  • Minimum coating thickness: 80–100 µm
  • Optional electrostatic powder coating in RAL colors for enhanced corrosion protection and aesthetics
  • Expected lifespan:
 • 30–50 years in standard environments
  • Minimum 20 years in marine or industrial conditions

5. Compliance Standards

  • Germany TÜV Certification: All structural reports certified by TÜV Rheinland / TÜV SÜD
  • Turkey TSE Standards: Compliant with TSE EN 1090-1 and TSE EN ISO 13920
  • ISO Standards:
  • ISO 9001:2015 – Quality Management
  • ISO 14001:2015 – Environmental Management
  • ISO 45001:2018 – Occupational Health and Safety

9. Certifications and Reports

  • Structural design compliant with EU CE marking regulations
  • Steel framework and membrane systems certified by TÜV Rheinland
  • CE-certified PVC membrane, tested for durability and safety
  • Reports generated using industry-standard software and backed with all necessary certifications

10. Warranty Terms

  • Steel Structure: 10-year manufacturer warranty
  • Galvanized Coating: 15-year anti-corrosion warranty
  • Includes:
  • Quality and coating thickness certificates
  • Corrosion resistance test reports
  • Maintenance:
  • No maintenance required under normal conditions
  • Annual visual inspections recommended in aggressive environments (coastal, industrial, etc.)

Unixpadel’s newly developed Retractable Side and Roof Canopy System offers an innovative, flexible, and highly durable solution for padel courts worldwide. Designed to withstand the harshest outdoor conditions and adaptable to all climate zones, this system merges engineering excellence with aesthetic appeal. The following technical data can be directly used in project tenders and specification documents.

1. Structural Design

  • Custom-engineered in accordance with EN 1990–1999 Eurocode standards
  • Adapted to the geographic and climatic conditions of each project site
  • Wind and snow loads are analyzed based on local building codes and regional requirements
  • All structural calculations are carried out using certified engineering software (SAP2000, RFEM, Robot Structural Analysis)

2. Steel Quality

  • Primary and secondary structural elements use high-strength steel: S355 grade or higher
  • Conforms to EN 10025-2 standard
  • All steel materials come with 3.1 certificates for traceability and compliance

6. Load Resistance and Performance Criteria

  • Wind Load: Engineered to withstand wind speeds of at least 110 km/h (per EN 1991-1-4)
  • Snow Load: Designed to resist a minimum of 90 kg/m², or higher depending on geographic location
  • Static Calculations: Validated by certified engineers; all reports included for tender documentation

7. Operational and Environmental Features

  • High UV resistance and heat-reflective technology
  • Up to 30–40% temperature reduction inside the court
  • High elasticity and impact resistance prevent thermal deformation
  • Aerodynamic design minimizes wind effect during play, enhancing gameplay comfort

8. Membrane Specifications

  • Material: High-tenacity polyester fabric with PVC coating
   • Weight: 1100 gr/m² • Features:
   • UV-blocking and sun-reflective
   • Fire-retardant: DIN 4102-B1 / EN 13501-1 B-s2,d0
   • Resistant to extreme heat and cold
   • REACH and RoHS compliant
   • Certified under EN 13773 and ISO 3795
